Futaba 10C 2.4GHz - Manual (Page 33)

33
PARAMETER submenu: sets those parameters you would likely set once, and then not disturb again.
Once you have selected the correct model you wish to work with, the next step is setting up the proper parameters for this
VSHFL¿FPRGHO
• What is the model's type?
• What type is the receiver’s modulation [FM (PPM
PCM or 2.4G-10CH7CH]?
• Does the model have a normal throttle on channel 3 or do you need full range
trim on channel 3 (ATL)?
• If you are utilizing either of the twin aileron functions, do you need to tell the
radio your receiver is only 5 channels?
First it is important to clear out any old settings in the memory from prior use, using the MODEL RESET.
MODEL RESET
: completely resets all data in the individual model you have currently selected. Don't worry - there is no way
you can accidentally delete all models in your radio with this function. Only a service center can completely reset your
radio's entire memory at once. To delete each model in your radio's memory (for example when selling), you must SELECT
each model, reset that memory, then go SELECT the next memory, etc.
Note that when you COPY one model memory into another or change the model's type, you need not delete all existing data
¿UVWE\XVLQJWKLVIXQFWLRQCOPY completely overwrites anything in the existing model memory, including MODEL NAME.
The MODEL TYPE function overwrites all data except name and MODUL.
GOAL of EXAMPLE: STEPS: INPUTS:
Reset model memory 1.
N O T E : T h i s i s o n e o f s e v e r a l
functions for which the radio requires
FRQ¿UPDWLRQWRPDNHDFKDQJH
Confirm you are currently using the
proper model memory. (Ex: 1) On home screen, check model name and
number on top left. If it is not correct,
use MODEL SELECT, p. 30.
Open PARAMETER submenu. for 1 second. (If ADVANCE, again.)
to 2nd page of menu.
C to PARAMETER.
Reset the Memory. for one second.
&RQ¿UPWKHFKDQJH
Are you sure? displays. *
Close.
Where next? Now that the memory is reset, name has returned to the default (Ex:
MODEL-0001
).
NAME the model: p. 32.
COPY a different model into this memory: p. 31.
SELECT a different model to edit or delete: p. 30.
Change the MODEL TYPE to glider or helicopter: see p. 34.
Change the receiver modulation [FM (PPM
PCM or 2.4G-10CH7CH]: see p. 35.
Utilize servo REVERSE: see p. 38.
Adjust servo travel with END POINT: see p. 39.
6HWXSGXDOWULSOHUDWHVDQGH[SRQHQWLDOD/R,EXP): see p. 42.
*Radio emits a repeating “beep” and shows progress on screen as the model memory is being reset. Note that if the power switch is turned off prior to
completion, the data will not be reset.
