46 - Basic Settings RocketLinx ES7528 User Guide: 2000509 Rev. C
Configuration Using the Web Interface
Basic Settings
The Basic Setting group allows you the ability to configure switch information, IP address, User name/
Password of the system. It also allows you to do firmware upgrade, backup and restore configuration, reload
factory default, and reboot the system.
The following web pages are included in this group:
• Switch Setting on Page 46
• Admin Password on Page 47
• IP Configuration on Page 48
• Time Setting on Page 50
• Jumbo Frame on Page 53
• DHCP Server Configuration on Page 54
• DHCP Leased Entries on Page 56
• DHCP Relay Agent on Page 57
• Backup and Restore on Page 58
• Firmware Upgrade on Page 63
• Load Default on Page 65
• System Reboot on Page 65
Optionally, you can use the CLI for configuration, see Basic Settings (CLI) on Page 151.
Switch Setting
You can assign the System Name, Location, Contact and view ES7528 information.
Switch Setting Page
System Name
You can assign a name to the ES7528. You can input up to 64 characters. After you
configure the name, The CLI system selects the first 12 characters as the name in
CLI system.
System Location You can specify the ES7528 physical location with up to 64 characters.
System Contact
You can specify contact people with up to 64 characters by typing the Administer’s
name, mail address or other information.
System OID
The SNMP Object ID of the ES7528. You can follow the path to find its private MIB
in an MIB browser.
Note: When you attempt to view private MIB, you should first compile private MIB
files into your MIB browser.
System Description Managed Gigabit PoE + Ethernet Switch.
