42 - Feature Overview RocketLinx ES7528 User Guide: 2000509 Rev. C
Configuration Using the Web User Interface
Port Status
Port Status on
Page 68
• Port Type
• Link - Up/Down
• State - Enable/Disable
• Speed/Duplex
• Flow Control
• SFP Vendor, Wavelength, and Distance
• SFP DDM - Temperature, Tx Power, and Rx Power
Port Trunk
Aggregation
Setting
on Page 72
Aggregation Status
on Page 73
Aggregation Settings
• Group ID - Trunk 1-8
• Trunk Type - Static or 802.3ad LACP
• Load Balance - MAC hash or IP hash
Aggregation Status by Trunk
• Type
• Aggregated Ports
• Individual Ports
• Link down Ports
PVLAN
Configuration
PVLAN
Configuration
on
Page 100
• VLAN ID
• PVLAN Type - None, Primary, Isolated, and Community
PVLAN Information
PVLAN
Information
on
Page 102
• Primary VLAN
• Secondary VLAN
• Secondary VLAN Type
• Ports
PVLAN Port
Configuration
PVLAN Port
Configuration
on
Page 101
Port Configuration
• PVLAN Port Type - Normal, Host, or Promiscuous
• VLAN ID
PVLAN Association
• Secondary VLAN
• Primary VLAN
QoS Setting
QoS Setting on
Page 103
Queue scheduling
• Use a Round Robin Scheme
• Use Weighted Round Robin Scheme
• Use A Strict Priority Scheme
•
Rate Control
Rate Control on
Page 70
• Ingress Rate (1 Mbps to 100Mbps)
• Egress Rate (1 Mbps to 100Mbps)
Type Category Details
