Comtrol ES7528 User Manual
Page 41

RocketLinx ES7528 User Guide: 2000509 Rev. C
Feature Overview - 41
Configuration Using the Web User Interface
PoE Status
Displays:
•
DC1/2 Power (V and W)
•
AC Power (V and W)
•
Primary/Secondary Power
•
Tertiary Power
•
Total Power Budget
•
Total Output Power
•
Power Budget Warning Level
•
Utilization
•
Event
Port by Port:
•
PoE Mode
•
Operation Status
•
PD Class
•
Consumption(W)
•
Voltage(V)
•
Current(mA)
Port Control
•
Enable/Disable Port State
•
Speed/Duplex - Auto-Negotiation, 10 Full/Half, 100 Full/
Half, and 1000 Full (Ports 25-28)
•
Flow control - Disable/Symmetric
•
User-Defined Description
Port Mirror Mode
•
Port Mirror Mode - Enable/Disable
•
Port by Port
- Source Port - Rx and Tx
- Destination Port - Rx and Tx
Port Statistics
Port by Port
•
Type
•
Link
•
State
•
Rx and Tx Good
•
Rx and Tx Bad
•
Rx Abort
•
Collision
Type
Category
Details
