RocketLinx ES7528 User Guide: 2000509 Rev. C
Configuration Using the Web User Interface - 31
Configuration Using the Web User Interface
The ES7528 provides in-band and out-band configuration methods:
•
Out-band management means that you configure the ES7528 using the RS-232 console cable and the
Command Line Interface (CLI) to access the ES7528 without attaching an admin PC to the network. You
can use out-band management if you lose the network connection to the ES7528. The CLI and Telnet are
discussed in
Configuration Using the Command Line Interface (CLI)
•
In-band management means that you connect remotely using the ES7528 IP address through the
network. You can remotely connect with the ES7528 embedded Java applet web user interface or a Telnet
console and the CLI. The ES7528 provides HTTP web user interface (
user interface (
) for web management.
Configuration Overview
This subsection discusses a minimum level of configuration required to operate the ES7528.
1.
If you have not done so, install the hardware, see
2.
If you are planning on using in-band management, you need to program the ES7528 IP address to meet
your network requirements. The easiest way to configure the IP address is using a Windows system and
PortVision DX, see
Configuring the Network Settings
3.
If you are planning on connecting PDs, see
on Page 74 to configure the PoE port
characteristics,.
4.
Configure other features as desired. You can refer to the
configuration information or use these links:
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
