Configuration Using the Command Line Interface
(CLI)
Overview
The ES7506 provides in-band and out-band configuration methods:
• Out-band management means that you configure the ES7506 using the RS-232 console cable and the
Command Line Interface (CLI) to access the ES7506 without attaching an admin PC to the network. You
can use out-band management if you lose the network connection to the ES7506.
• In-band management means that you connect remotely using the ES7506 IP address through the
network. You can remotely connect with the ES7506 embedded Java applet web user interface or a Telnet
console and the CLI.
If you are planning on using in-band management, you need to program the ES7506 IP address to meet your
network requirements. The easiest way to configure the IP address is using a Windows system and
NetVisionPortVision DX, which is discussed in
Configuring the Network Settings on Page 17.
If you want to use the web user interface for configuration, see Configuration Using the Web User Interface on
Page 31.
Use the following procedures to access the ES7506 using the CLI:
• Using the Serial Console
• Using a Telnet/SSH Console
This section contains information about the following groups of commands:
• Basic Settings (CLI) on Page 108
• Port Configuration (CLI) on Page 114
• Power over Ethernet (CLI) on Page 117
• Network Redundancy (CLI) on Page 121
• VLAN (CLI) on Page 160
• Traffic Prioritization (CLI) on Page 127
• Multicast Filtering (CLI) on Page 130
• SNMP (CLI) on Page 133
• Security (CLI) on Page 134
• Warnings (CLI) on Page 136
• Monitor and Diag (CLI) on Page 139
• Saving to Flash (CLI) on Page 141
• Logging Out (CLI) on Page 141
