122 - Network Redundancy (CLI) RocketLinx ES7506 User Guide: 2000529 Rev. F
Configuration Using the Command Line Interface (CLI)
RSTP (cont.)
Port Priority
Switch(config-if)# spanning-tree port-priority
<0-240> Number from 0 to 240, in multiple of 16
Switch(config-if)# spanning-tree port-priority 128
bpdufilter Switch (config-if)# spanning-tree dpdufilter enable
bpduguard Switch (config-if)# spanning-tree dpduguard enable
Link Type -
Auto Switch(config-if)# spanning-tree link-type auto
Link Type - P2P Switch(config-if)# spanning-tree link-type point-to-point
Link Type –
Share Switch(config-if)# spanning-tree link-type shared
Edge Port
Switch(config-if)# spanning-tree edge-port enable
Switch(config-if)# spanning-tree edge-port disable
RSTP Info
Active status
Switch# show spanning-tree active
Rapid Spanning-Tree feature Enabled
Spanning-Tree BPDU transmission-limit 3
Root Address 00c0.4e2D.0386 Priority 4096
Root Path Cost : 200000 Root Port : 7
Root Times : max-age 20 sec, hello-time 2 sec, forward-delay 15 sec
Bridge Address 00c0.4e2D.0102 Priority 4096
Bridge Times : max-age 10 sec, hello-time 2 sec, forward-delay 15 sec
Aging time : 300
Port Role Port-State Cost Prio.Nbr Type
------- ---------- ------------ --------- ---------- -----------
fa1 Root Forwarding 200000 128.1 P2P(RST) N/A
fa4 Designated Forwarding 200000 128.4 P2P(RST) N/A
