128 - Traffic Prioritization (CLI) RocketLinx ES7506 User Guide: 2000529 Rev. F
Configuration Using the Command Line Interface (CLI)
QoS Setting (Continued)
QoS Priority Mode
Switch(config)# qos priority
cos CoS
dscp DSCP/TOS
port-based Port-based
Switch(config)# qos priority dscp
Switch# show qos priority
QoS Priority Mode: DSCP
Display - Queue
Scheduling
Switch# show qos queue-sched
QoS queue scheduling scheme : Weighted Round Robin (Use an
8,4,2,1 weight)
Display - Port Setting -
Trust mode
Switch# show qos trust
QoS Port Trust Mode :
Port Trust Mode
-----+------------
1 COS first
2 COS only
3 COS only
4 COS only
5 COS only
6 COS only
CoS-Queue Mapping
Format
Switch(config)# qos cos-map
PRIORITY Assign an priority (3 highest)
Switch(config)# qos cos-map 1
QUEUE Assign an queue (0-3)
Note: Format: qos cos-map priority_value queue_value.
Map CoS 0 to Queue 1
Switch(config)# qos cos-map 0 1
The CoS to queue mapping is set ok.
Map CoS 1 to Queue 0
Switch(config)# qos cos-map 1 0
The CoS to queue mapping is set ok.
Map CoS 2 to Queue 0
Switch(config)# qos cos-map 2 0
The CoS to queue mapping is set ok.
Map CoS 3 to Queue 1
Switch(config)# qos cos-map 3 1
The CoS to queue mapping is set ok.
Map CoS 4 to Queue 2
Switch(config)# qos cos-map 4 2
The CoS to queue mapping is set ok.
Map CoS 5 to Queue 2
Switch(config)# qos cos-map 5 2
The CoS to queue mapping is set ok.
Map CoS 6 to Queue 3
Switch(config)# qos cos-map 6 3
The CoS to queue mapping is set ok.
Map CoS 7 to Queue 3
Switch(config)# qos cos-map 7 3
The CoS to queue mapping is set ok.
