RocketLinx ES7506 User Guide: 2000529 Rev. F
PoE Control - 63
Configuration Using the Web Interface
Power Over Ethernet Control Page
Powering Mode
PoE Mode
Each port’s ability to deliver power can be individually enabled or
disabled using the PoE Mode combo box. You can select 802.3af or
forced.
Power Mode
There are three power modes available for each port.
•
Standard mode delivers power following the IEEE 802.3af
specification.
•
Manual mode allows the user to specify the wattage limit
delivered to an IEEE 802.3af device.
•
Ultra mode should be used for IEEE802.3at power
requirements and allows the user to configure the wattage
limit above 15.4 watts.
Note: To deliver higher amounts of power the ES7506 must be
powered with a 55VDC power supply.
When delivering more than 15.4W of power, ensure the
ES7506 is mounted on panel capable of dissipating heat.
Also ensure the temperature where the ES7506 is located is
kept under 60
°
C. Delivering power above 15.4W causes the
ES7506 to generate more heat.
Power Limit
The limitation of the output power (watts) range is standard mode:
N/A, Manual mode: 0.44 - 15.4W, and Ultra mode: 0.44 - 30W.
PD Status Detection
PD Status Detection
Enable/Disable PD Status Detection function.
IP Address
Type in the IP address that you want to detect.
Cycle Time(s)
This is the gap per detection in seconds.
Apply
Click Apply to apply the settings.
Note: You must Save the settings (
), if you want maintain
these settings if the ES7506 is powered off.
