38 - Feature Overview RocketLinx ES7506 User Guide: 2000529 Rev. F
Configuration Using the Web User Interface
IGMP Snooping
IGMP Snooping on
Page 75
• Enable/Disable
• VID
• Port by Port IGMP Snooping Table
- IP Address
- VID
IP Configuration
IP Configuration
on Page 45
• IPv4
• DHCP
• DNS1 and DNS2
IP Security
IP Security on
Page 80
• Enable/Disable
• Security IP
• Security IP List - Index and Security IP
MAC Address Table
(8K) MAC Address
Table
on Page 86
• Aging Time (Sec)
• Static Unicast MAC Address - MAC Address, VID, and
Port
• Port by Port MAC Address Table View
- Static Unicast
- Dynamic Unicast
- Static Multicast
- Dynamic Multicast
Ping Utility
Ping Utility on
Page 91
Target IP Address
PoE Control
PoE Control on
Page 62
• Powering Mode - 802.3af or Force
• Port by Port
- PoE - Enable/Disable/Schedule
- Power Mode - 802.3af or Force
• PD Status Detection - Enable/Disable
- PD IP Address
- Cycle Time
PoE Scheduling
PoE Scheduling on
Page 64
PoE Ports On/Off on an hourly/daily basis.
PoE Status
PoE Status on Page
64
Port by Port:
• PoE Mode
• Operation Status
• PD Class
• Consumption(W)
• Voltage(V)
• Current(mA)
Type Category Details
