RocketLinx ES7506 User Guide: 2000529 Rev. F Feature Overview - 39
Configuration Using the Web User Interface
Port Control
Port Control on
Page 58
• Enable/Disable Port State
•
• Flow control - Disable/Symmetric
• User-Defined Description
Port Statistics
Port Statistics on
Page 88
Port by Port
• Type
• Link
• State
• Rx and Tx Good
• Rx and Tx Bad
• Rx Abort
• Collision
Port Status
Port Status on
Page 60
• Port Type
• Link - Up/Down
• State - Enable/Disable
• Speed/Duplex
• Flow Control
Port-Based VLAN
Port Based VLAN
on Page 70
• Management VLAN ID (1-4094)
• PVID
• Allow to send to
• Egress Tagged/Untagged
QoS Setting
QoS Setting on
Page 71
Queue scheduling
• Use 8.4.2.1 Weighted Fair Queuing Scheme
• Use A Strict Priority Scheme
Port Setting
• CoS - 0 through 3
• Trust Mode - COS Only, DSCP Only, COS First, DSCP
First, or Port Based
Rate Control
Rate Control on
Page 61
• Ingress Packet Types - Broadcast Only, Broadcast/
Multicast, Broadcast/Multicast/Unknown Unicast, and
All
• Ingress Rate/Egress Rate (No-limit, 128Kbps, 256Kbps,
512Kbps, 1024Kbps, 2048Kbps, 4096Kbps, and
8192Kbps)
•
Type Category Details
