Device front panel – Comtrol ES7506 User Manual
Page 92
92 - Device Front Panel
RocketLinx ES7506 User Guide: 2000529 Rev. F
Configuration Using the Web Interface
Device Front Panel
The Device Front Panel allows you to see the LED status of the ES7506.
Note: There is not a CLI command for this feature. If you can view the physical LEDs, you can use the
on Page 12, which provide detailed LED information.
LEDs
LED On/Link
Up
LED Off/Link Down
Alm (Alarm)
Red
White
PW1
Green
White
PW2
Green
White
R.M. (Ring
Master)
Green
White
PoE 1-4
Green
White
LNK/ACT 1-6
Green
White
