DTSS provides another method to selectively communicate
with specific stations. The squelch on the transceiver
opens only when the same 3-digit DTMF (Dual Tone Multi-
Frequency) code is received that is programmed in this
transceiver. You can select a 3-digit code from among
1000 combinations, 000 to 999.
STORING DTSS CODES
DUAL TONE SQUELCH SYSTEM (DTSS)
Note:
Be aware that audible DTMF tones from other transceivers near you
may be picked up by your MC-53DM or MC-45 microphone. If so,
this could prevent the functions described in this chapter from
working correctly.
DTSS does not function while you are storing DTSS codes even if a
code is received that matches one already stored in memory.
Using the Tuning Control or
Microphone [UP]/[DWN]
1 Press [F] (1 s) to access Menu A.
2 Select “DTC” {page 17}.
• The current DTSS code appears. The default is 000.
MENU /
Jl J Г nt nt nt '■»
JJ I и и и
MHz
-5-------- 7------- 9-------- OVER
TONE REV
6
7
Press [VFO].
• The first digit blinks.
Use the Tuning control or microphone [UP]/[DWN]
to select the first digit.
Repeat Steps 3 and 4 to select the second and third
digits.
Press [VFO] again to complete your selection.
Press [F] or microphone [PTT] to exit Menu A.
Using the Microphone DTMF Keypad
This function can be used only when the MC-53DM
microphone is used.
1 Press [F] (1 s) to access Menu A.
2 Select “DTC” {page 17}.
• The current DTSS code appears. The default is 000.
3 Press [VFO].
• The first digit blinks.
4 Press the correct numeric digit to select the first digit.
5 Repeat Step 4 to select the second and third digits.
6 Press [F] or microphone [PTT] to exit Menu A.
Note: If you press buttons other than microphone [UPJ/[DWN] and
the microphone numeric keys, or if you do not make a DTSS code
entry within 10 seconds, the previous mode is restored. Digits
already entered will be stored.
37
