DISPLAY
Ф (3) (4) ® ® ®
wO R CT DT CO MENU j
*
S
\ ДРД
LM
- 1 ---- 3 -------5 7------ 9------- OVER ON AIR
Ф
Indicates the Transceiver Lock function is ON {page 46}.
® CT
‘T' indicates the subaudible Tone encoder function is ON
{page 22}. “CT’ indicates the CTCSS function is ON
{page 36} provided the optional TSU-8 CTCSS unit is
installed {page 54}.
(D
DT
Indicates the Dual Tone Squelch System (DTSS) is ON
{page 37}.
® CO
Indicates Carrier-Operated Scan Resume is ON {page 31}.
When not visible, Time-Operated Scan Resume is in effect.
® - +
Indicates the transmit frequency is offset (different) from the
receive frequency {page 22}. The symbol displayed (either
“ + ” or “ - ”) indicates the direction that the transmit
frequency is offset from the receive frequency. +”
appears when a split-frequency memory channel is
selected {page 25}.
® R
Indicates the Reverse function is ON {page 23}. Transmit
and receive frequencies are reversed. If any frequency is
selected for ‘TONE.RX” in Menu B, RX Tone frequency and
TX Tone frequency also are reversed. Refer to “Selecting a
Tone Frequency” {page 23}.
(7) MENU
Visible while accessing Menu A or Menu B {page 17}.
® S.Mli.i.ts
Displays the transmit/receive frequency, frequency step
{page 45}, Offset frequency {page 21} and other data. Also
displays the menu selections when using Menu Set-Up.
The 1 MHz decimal point blinks while the transceiver is
scanning {pages 32, 35}.
® gg
Displays the currently selected memory channel number
{page 26}. The first digit displays “A” or “B” depending on
which Menu is being accessed.
