MACHINE ALIGNMENT REPORT
JOB NAME COUPLING SIZE
JOB NUMBER TYPE
MACHINE SER. NO. WEAR CONDITION
DRIVER TYPE SPACER LENGTH
HOT CHECK
□
COLD CHECK
□
COMPRESSOR COUPLING
Open ’’
On ’’
Top □
Bottom □
Diam
Step 1 — Angular in Elevation
Gear
□
Hi
□
Drive □ ’’ Lo □
DRIVE COUPLING
Open ’’
On ’’
Top □
Bottom □
Diam
Step 2 — Parallel in Elevation
Open ’’
On ’’
In □
Out □
Diam
Step 3 — Angular in Plan
Gear
□
In
□
Drive □ ’’ Out □
Step 4 — Parallel in Plan
Drive ’’
Hi
□
Lo □
Open ’’
On ’’
In
□
Out □
Diam
Drive ’’ In □
Out □
KEY: In — Side toward compressor discharge (side next to cooler).
Out — Side opposite compressor discharge (side furthest from cooler).
SIGNED
DATE
Copyright 1995 Carrier Corporation
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
