INITIAL START-UP CHECKLIST FOR
17/19EX CENTRIFUGAL LIQUID CHILLER
(Remove and use for job file.)
MACHINE INFORMATION:
NAME JOB NO.
ADDRESS MODEL
CITY STATE ZIP S/N
DESIGN CONDITIONS:
TONS BRINE
FLOW
RATE
TEMPERATURE
IN
TEMPERATURE
OUT
PRESSURE
DROP
PASS
SUCTION
TEMPERATURE
CONDENSER
TEMPERATURE
COOLER ******
CONDENSER ******
COMPRESSOR: Volts RLA OLTA
STARTER: Mfg Type
OIL PUMP: Volts RLA OLTA
REFRIGERANT: Charge Lbs
CARRIER OBLIGATIONS: Assemble . . . . . . . . . . . . . . . Yes Ⅺ No Ⅺ
Leak Test . . . . . . . . . . . . . . . Yes Ⅺ No Ⅺ
Dehydrate . . . . . . . . . . . . . . . Yes Ⅺ No Ⅺ
Charging . . . . . . . . . . . . . . . . Yes
Ⅺ
No
Ⅺ
Alignment . . . . . . . . . . . . . . . Yes Ⅺ No Ⅺ
Operating Instructions Hrs.
START-UP TO BE PERFORMED IN ACCORDANCE WITH APPROPRIATE MACHINE START-UP
INSTRUCTIONS
JOB DATA REQUIRED:
1. Machine Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . Yes Ⅺ No Ⅺ
2. Machine Assembly, Wiring and Piping Diagrams . . . . . . . . . . . . Yes Ⅺ No Ⅺ
3. Starting Equipment Details and Wiring Diagrams . . . . . . . . . . . . Yes Ⅺ No Ⅺ
4. Applicable Design Data (see above) . . . . . . . . . . . . . . . . . . . . . . Yes Ⅺ No Ⅺ
5. Diagrams and Instructions for Special Controls . . . . . . . . . . . . . Yes Ⅺ No Ⅺ
INITIAL MACHINE PRESSURE:
YES NO
Was Machine Tight?
If Not, Were Leaks Corrected?
Was Machine Dehydrated After Repairs?
CHECK COMPRESSOR OIL LEVEL AND RECORD:
ADD OIL: Yes
Ⅺ
No
Ⅺ
Amount:
RECORD PRESSURE DROPS: Cooler Condenser
CHARGE REFRIGERANT: Initial Charge Final Charge After Trim
