Example Wiring Options

(continued)

Daisy Chain Zones Located Remote

to Main Panel (Up to 500 Feet)

Main Panel

Expander Panel

Zones 5-6

Expander Panel

As Needed

Expander Panel

Zones 7-8

500 Ft. (Maximum)

21

Main Panel

Expander Panel

Zones 5-6

Expander Panel

As Needed

500 Ft. (Maximum)

Expander Panel

As Needed

Expander Panel

As Needed

Daisy Chain Zones Located Remote to Main Panel -

Remote Panels Wired in Star Configuration

NOTE: To prevent possible interference do not run low voltage
wiring along side 120VAC wiring or magnetic ballasts.
