Installer Guide
7390 Wireless Remote Indoor Sensor
®
TM
smart connect
Please read all instructions before proceeding.
The wireless remote indoor sensor monitors temperature at a remote indoor
location and transmits the temperature data wirelessly to the thermostat. The
thermostat can be set to monitor temperature at the thermostat location, at
the sensor location or by combining the temperature at the thermostat and the
remote location(s). Up to 4 wireless indoor remote sensors can be connected.
1 Specifications
Operating Temperature: 40 - 99 ˚F
Storage Temperature: 14 - 140 ˚F
Operating Humidity: 5 - 95% Rh Control Range: 45 - 90˚F
Battery Power: 3.0 Volt DC
Accuracy: +/- 1˚F
7390-100-01
Blue LED Indicator
- 1 flash every 30 seconds: Normal operation
- 3 flashes every 30 seconds: Sending sensor data to thermostat
- 1 flash every 2 seconds: Sensor is in pairing mode
- Solid for 60 seconds:
Successfully paired remote sensor
Red LED Indicator
- 3 flashes every 30 seconds: Low battery
- 1 flash every 10 seconds: Lost communication with thermostat
IMPORTANT: Before mounting the remote sensor, you should verify there is good
wireless communication in the area you wish to mount it by first pairing it in that
location. If you are having trouble pairing in that location, try moving the remote
sensor to a location closer to the thermostat.
