33
Once you have reached the preset number of
measurements (n = ...) you might be prompted
to enter a name for the checkzone (“Input
Checkzone” aktivated).
Proceed by entering the name of the checkzone as
described above for the parameters.
If “Input Checkzone” is deactivated, the instrument
automatically assigns the name SAMPLE 01 and
then increments this name.
To exit the test series, presss the scroll wheel and
activate End Test Series.
Measure
SAMPLE01 n = 2/3
x R
Wa 10.8 11.5 1.8
Wb 17.4 17.8 2.1
Wc 8.7 9.2 0.9
Wd 12.3 12.9 1.4
SW 15.7 15.5 0.8
LW 7.8 7.3 1.2
