30
Measure
8.3 Organizer
An organizer file defines a test sequence for user
guidance, e. g. for measuring a car body with
several checkzones. These files can be generated
with the smart-chart software.
If no Organ izer is loaded in the device, one must
be transferred from a PC.
Once an Organizer is selected, a menu appears
for Parameter 2 of the Organizer. Colors are listed
as an example of this in the menu to the side.
After you have selected the appropriate color, a
selection menu appears for Parameter 3.
The illustrated example features automotive paint
lines.
If “Input Comment” is activated in the Organizer,
you are prompted to enter additional information.
If “Input ID” is activated in the Organizer, you are
prompted to enter a code, e.g. the vehicle ID.
Upon definition of all parameters, the following
measurement series is identified and the
instrument goes into measurement mode.
