Table 8-4: EXPERT Menu Sub-Menus and Parameters (Continued)
FUNCTION DESCRIPTION
ENTRY
RANGE
DEFAULT
INSTALLATION Sub-Menu (Continued)
HYSTERESIS
Dynamic Switching hysteresis stage 1.
(Not Applicable) 5K - 20K
(N/A)
5.0K
(N/A)
FOUND MODULS
Display of heat generators automatically
reported via BUS with BUS ID. Displays the
number of heat modules available for service.
display
CAP/MODULE
After restarting, the Controller, searches the bus
systems for available new heat modules and the
maximum kW output of each heat module.
00 - 1000 kW 40 kW
NEW CONFIG
If the BUS configuration was modified, the
automatic search for generators on the BUS may
be activated here.
(Currently Not Applicable)
00, 01
(OFF/ON)
(N/A)
00
(N/A)
MIN MOD CASC
Specifies the number of heat modules started
simultaineously.
01 - 08 01
HW-BOILER Number of stages for HW operation 00 - 08 00
CONTR DEVIAT
Control Deviation indicates the temperature
difference between the header set point and the
actual temperature.
display F
DES OUPUT Required system output [in %] 0 - 100% 00
SWITCH TIME Internal control value: only for switching cascade (-99) - 0 - (99)
Display
(N/A)
BLOCK TIME Not Applicable (N/A) (N/A)
MAX T-MODUL Maximum temperature of Heat Module
122.0°F –
230.0°F
194.0°F
DYN UPWARD
Dynamic heat generator connection
(Not Applicable)
(N/A) (N/A)
DYN
DOWNWARD
Dynamic heat generator deactivation
(Not Applicable)
(N/A) (N/A)
RESET TIME Resetting time for Controller (seconds) 5 - 500 50
MODULAT MAX
Start Level. If this modulation percentage is
exceeded, the next heat generator (module) is
connected after the delay time specified by the
SEQ SW TIME (see below) elapses.
50% - 100% 30%
MODULAT MIN
Stop Level. If value drops below this modulation
percentage, the last heat generator (module) of
the current sequence is switched off
10% - 60% 35%
MIN MOD HS Connection of the next heat generator 0% - 60% 35%
MOD LEVEL HW
Entry of the set modulation percentage for the
heat generators in hot water operation
(Currently Not Applicable)
40% - 100%
(N/A)
80%
(N/A)
SEQUENCE 1 Boiler sequence 1 12345678
SEQUENCE 2 Boiler sequence 2 87654321
