PR1: 11/30/12 Page 36 of 112
GF-115-C Modulex E8 Controller and BCM
Operations and Maintenance Manual
OMM-0084_0D
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 • Ph: 800-526- 0288
Table 4-6: SERVICE Menu Listing (Continued)
FUNCTION DESCRIPTION REMARKS
SENSOR TEST Sub-Menu
F11
Flow temperature heating circuit 1 or temperature
multifunction 1
F12
Hot water temperature lower or temperature
multifunction 2
F13
Solid fuel boiler temperature or collector 2 or
temperature multifunction 3
F14
Collector 1 temperature or temperature
multifunction 4
F15; Light; 0-10V I
Room temperature heating circuit 2 or measured
value of the light sensor or voltage value 0-10V
input
OTHER ENTRIES
Additional items and functions in the SERVICE Sub-Menu include the following:
SW NO XXX-XX
Specifies the Software Version and Index number
currently installed in the Controller
CASCADE MANU
(1-8)
Starting different burner stages of the cascade
See GF-115-H, Section 7, Sub-section 7.5 for
additional startup instructions using these sub-
menu functions.
BURNER TIME (1-
8)
Program Key – Burner time for all stages
BURNER START
(1-8)
Program Key – Burner start for all stages
LIMITER TEST
(1-8)
Safety temperature limiter test with heat generator
temperature display
Start with Program Key (hold down)!
SERVICE Input of date or operating hours for service
messages
WARNING: NEVER ATTEMPT TO USE THE FOLLOWING RESET FUNCTIONS.
RESET USER 00 DO NOT USE
RESET EXPERT
00
DO NOT USE
RESET T-PRG 00 DO NOT USE
RETURN Exit level using Program Key
