Table 4-3: EXPERT Menu Listing (Continued)
FUNCTION DESCRIPTION ENTRY RANGE DEFAULT
INSTALLATION Sub-Menu (Continued)
HYSTERESIS Not Applicable –
FOUND
MODULS
Displays the number of heat modules available
for service.
Display
CAP/MODULE
Displays the maximum Kw output of each heat
module.
00 – 1000 Kw 40 Kw
NEW CONFIG Not Applicable
MIN MOD
CASC
Not Applicable 01 – 08 01
HW-BOILER Not Applicable 00 – 08 00
CONTR
DEVIAT
Control Deviation indicates the temperature
difference between the Boiler set point and the
actual water temperature.
Display °F
DES OUPUT Required system output [in %] 0 – 100% 00
SWITCH TIME Not Applicable (N/A)–– (N/A)
BLOCK TIME Not Applicable (N/A) (N/A)
MAX T-
MODUL
Maximum temperature of Heat Module 122.0°F to 230.0°F 194.0°F
DYN
UPWARD
Not Applicable (N/A) (N/A)
DYN
DOWNWARD
Not Applicable (N/A) (N/A)
RESET TIME Not Applicable 5 – 500 50
MODULAT
MAX
Start Level. If this modulation percentage is
exceeded, the next heat module is connected
after the delay time elapses.
50% - 100% 30%
MODULAT
MIN
Stop Level. If value drops below this
modulation percentage, the last heat generator
(module) of the current sequence is switched
off
10% - 60% 35%
MIN MOD HS Not Applicable 0% - 60% 35%
MOD LEVEL
HW
Not Applicable
SEQUENCE 1 Boiler sequence 1 12345678
SEQUENCE 2 Boiler sequence 2 87654321
