Table 4-7: INSTALLATION Menu Listing
PARAMETERS DESCRIPTION ENTRY RANGE DEFAULT
INSTALLATION Sub-Menu
LANGUAGE Set Language ENGLISH
TIME Set current time (min., hrs) 00:00 – 24:00
YEAR Set current year XXXX (4 digits)
MONTH Set current month 00-12
DAY Set current day of month 00-31
CONF DEVICE Confirm Device - - - -, 01 – 06 - - - -
HEATSOURCE 1 Heat Source 1 00 – 06 06
HS1 BUS Heat Source 1 Bus 00 – 04 02
HEATSOURCE 2 Heat Source 2 00 – 05 00
STORAGE HS2 Storage Heat Source 2 00 – 03 00
BUFFER Buffer 00, 01, 02 00
HC FUNCTION 1 Heating Circuit Function 1 00, 01, 03 00
HC FUNCTION 2 Heating Circuit Function 2 00 – 04 00
CAP/MODULE See Paragraph 4.8.1 for instructions. 00 – 1000 Kw 40 Kw
RELAY FUNC 1 Relay Function 1 (See Paragraph
4.8.2)
00 – 26 00
T-MF1 SETP Temperature – Multifunction Relay 1
Setpoint
86°F – 194°F 86°F
MF1 HYST Multifunction Relay 1 Hysteresis 4°F – 18°F 9°F
RELAY FUNC 2 Relay Function 2 (See Paragraph
4.8.2)
00 – 26 00
T-MF2 SETP Temperature – Multifunction Relay 2
Setpoint
86°F – 194°F 86°F
MF2 HYST Multifunction Relay 2 Hysteresis 4°Ra – 18°Ra 9°F
RELAY FUNC 3 Relay Function 3 00 – 26 01
T-MF3 SETP Temperature – Multifunction Relay 3
Setpoint
86°F – 194°F 86°F
MF3 HYST Multifunction Relay 3 Hysteresis 4°F – 18°F 9°F
RELAY FUNC 4 Relay Function 4 00 – 26 02
T-MF4 SETP Temperature – Multifunction Relay 4
Setpoint
86°F – 194°F 86°F
MF4 HYST Multifunction Relay 4 Hysteresis 4°F – 18°F 9°F
BUS ID 1 Bus Identification No. 1 00 – 15 01
BUS ID 2 Bus Identification 2 00 – 15 02
5K SENSOR 5,000 Ohm Sensor 00=5K, 01=1K 00 = 5 K
