Page 34: Service, Figure 4-6: service menu flow chart

PR1: 11/30/12
Page
34 of 112
GF-115-C
Modulex E8 Controller and BCM
Operations and Maintenance Manual
OMM-0084_0D
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 • Ph: 800-526- 0288
4.6.2 SERVICE Menu
The SERVICE Menu contains all the test and diagnostic functions/values required for
Customer Service Engineers to troubleshoot the equipment in a timely manner. The SERVICE
Menu items are illustrated and described in
Figure 4-6 and Table 4-6 respectively.
Some of the functions in this Sub-Menu require a valid Code No. (password) to be entered,
prior to accessing/changing Function values. When prompted by a “
CODE NO.” display, enter
0000 (four zeros) by pressing the Program Key four (4) times. This will allow function access.
SERVICE
SENSOR TEST
F1
F2
F3
F5
F6
F8
F9
F11
F12
F13
F14
RELAY TEST
CODE NO
01 - 11
SW NO 259-04
BURNER TIME
BURNER START
LIMITER TEST
SERVICE
RESET USER
RESET EXPERT
RESET PRG
RETURN
RETURN
CASCADE MANU
BOILER 01 – 00%
BOILER 02 – 00%
BOILER 03 – 00%
BOILER 04 – 00%
BOILER 05 – 00%
BOILER 06 – 00%
BOILER 07 – 00%
BOILER 08 – 00%
BOILER INT – 00%
RETURN
Figure 4-6: SERVICE Menu Flow Chart
