PR1: 11/30/12 Page 37 of 112
GF-115-C Modulex E8 Controller and BCM
Operations and Maintenance Manual
OMM-0084_0D
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 • Ph: 800-526- 0288
4.7 E8 Controller Initial Startup
Initial startup of the Modulex Controller requires a number of one-time entries to be made in
the initial INSTALLATION Menu that appears in the display when the E8 controller door is first
opened. Table 4-7 on the next page lists the description, entry range, and default entry for all
parameter. Instructions for entry into this menu is shown below.
NOTE
All items in the INSTALLATION Menu must be entered in
sequence. Press the Program Key to step through the menu
functions. Use Rotary Knob to adjust/change entries. Press the
Program Key to store entries and sequence to the next menu
item.
Initial Startup INSTALLATION Entry
1. Set the POWER rocker switch, located to the right of the Controller, to the ON (1)
position.
2. Open the panel cover on the Controller. The LCD display will read INSTALLATION. All
values in this level must be entered, in sequence, without interruption. The initial entries
required include: LANGUAGE, TIME and DATE as shown in the INSTALLATION Table
at right.
3. The first function that appears is LANGUAGE. By default, the display should show
ENGLISH. If ENGLISH is not displayed, turn the Rotary Knob until ENGLISH appears.
4. Press the Program Key to store setting.
5. Next, TIME will be displayed. Enter the current time (minutes, hours) using the Rotary
Knob. Press the Program Key to store each value.
6. The next items displayed are the YEAR, MONTH and DAY. Enter each item using the
Rotary Knob and press the Program Key as previously described to store the entry.
7. Following entry of all LANGUAGE, TIME and DATE entries, continue entering the
remaining items shown in Figure 4-7 and Table 4-7 until all required items have been
entered. Use the Program Key and Rotary Knob to select, adjust and store all entries as
previously described.
8. Continue step 7 until RETURN appears in the display, indicating that you are at the end
of the INSTALLATION menu.
9. Press the Program Key to exit the INSTALLATION menu.
