A&D Weighing ML-50 - Manual (Page 70)

MS-70 / MX-50 / MF-50 / ML-50 68
MS-70 MX-50 MF-50 ML-50
Operation environment 5°C to 40°C (41°F to 104°F), 85%RH or less (no condensation)
Sample pan
φ
85 mm
Power source,
Maximum current (r.m.s),
Maximum consumption
AC100V to 120V, 3A or AC200V to 240V, 1.5A
50Hz or 60Hz, Approximately 400W
Please confirm that this analyzer is correct for your local
voltage and receptacle type.
External dimensions 215(W) x 320(D) x 173(H)mm, 8.46(W) x 12.60(D) x 6.81(H)in.
Mass (Net weight) Approximately 6kg (without accessories)
1: After preheating the analyzer, the data can be obtained with approximately 5 g test
sample (Sodium tartrate dihydrate) in standard mode (MID.), standard drying, 160 °C
2: When change of moisture content per one minute reaches the preset termination
value, the measurement is completed.
16.1. 16.1. 16.1. 16.1. Dimensions Dimensions Dimensions Dimensions
