KEYENCE BL-N90 Series User Manual
Page 90
A-3 Using the Wall Mount with the Communication Unit
-8
Ap
pend
ices
When using the cup holder, install the cup holder before mounting the communication unit to
the wall.
Procedure
1
When inserting the communication unit into the cup holder, press it until it is secured in
place with the tabs.
Installing the cup holder to the communication unit
CAUTION
The cup holder holds the BL-N90 firmly in the communication unit. Be careful
when removing the BL-N90. If you pull on it too hard, the communication unit
may break or separate from the wall.
