Sending the Reading Data
Read barcode data is sent to the computer connected to the communication unit with the
following information added to the data: header, symbol identifier, and terminator.
If the barcode cannot be read correctly, the data is not sent.
Data Format
* Special characters are not needed to divide the data into segments 1 to 4.
Factory default values
•
Header
: None
•
Symbol identifier : Not added
•
Terminator
: [CR]
These settings can be changed (
z
Details of the format data
1 Header
A character can be added to indicate the start of data.
•
This parameter can be set to None, [STX], or [TAB] (HT).
2 Symbol identifier
A symbol identifier can be added to the barcode.
Code type
Data specifications
Symbol
identifier
CODE39
No check digit
]A0
Inspect check digit (Sent)
]A1
Inspect check digit (Not sent)
]A3
ITF
No check digit
]I0
Inspect check digit (Sent)
]I1
Inspect check digit (Not sent)
]I2
Codabar (NW-7)
–
]F1
Header
Symbol identifier
Read data
Terminator
1
2
4
3
