LS-Navigator Overview
This chapter describes the functions and setting conditions for the LS-Navigator.
1. Receives program settings for the controller on the computer and allows the user to verify the data.
2. Sends settings created on the computer to the controller and sets the program.
3. Reduces the time for settings with copy and paste functions when making settings for multiple controllers or
programs.
The following settings (parameters) for the controller can be verified and changed. Use the controller to change
parameters that are not listed.
Valid parametersDefault values
Controller program setting function
[OUT1] [OUT2]
[Limit settings]
Limit UPPER 1 1
STANDARD 10 10
LOWER -1 -1
HH 40 40
HI 30 30
LO 0 0
LL -10 -10
HOLD-H ON/OFF OFF OFF
Setting value 0 0
HOLD-L ON/OFF OFF OFF
Setting value 0 0
[Output settings]
Calculation A1 +1 0
A2 0 +1
Averaging times 512 512
Measurement mode Normal Normal
Self-timing time 100 100
Offset 0 0
Analog output Scaling value 1000 1000
+10V = 30 30
-10V = 0 0
[Area 1] [Area 2]
[Area settings]
Head Head 1 Head 1
Area settings Area DIA DIA
SEG (start) +2E +2E
SEG (end) +3E +3E
Area check OFF OFF
Edge detection threshold 50 50
[Calibration settings]
Calibration T1-A 0 0
T2-A 0 0
T1-B 0 0
T2-B 0 0
