■ Basic setting mode
You can set the following functions in the basic setting mode.
● How to enter the basic setting mode
Enter the basic setting mode by the following procedure.
• In the main display, press the [MODE] button and the [SET] button
at the same time for at least two seconds.
No. Item Description
Measurement
direction change Set the "Normal" or "Reverse" when the
spindle of the sensor head is inserted.
Multiplier Set the ratio of the detected value.
Output mode Set "ON (N.O.)" or "OFF (N.C.)" for output judgment.
Displayed
number of digits
Set the number of display digits.
Hysteresis Set the hysteresis value.
Batch input
setting Set to make input concurrently to all added expansion units
when an input is made to the input line of the main unit.
Special output
setting
Select the function of the special output lines.
-
Limit output HH
side teaching
Set the reference position where the limit
output turns on toward the spindle contraction
side when the "Lt.USEr" is selected in
.
Limit output HH
side criterion
position setting With the reference position being 0, set the
position where the limit output of the
contraction side turns on.
-
Limit output LL
side teaching
Set the reference position where the limit
output turns on toward the spindle extension
side when the "Lt.USEr" is selected in
.
Limit output LL
side criterion
position setting With the reference position being 0, set the
position where the limit output extension side
turns on.
Setting value
input screen
Static hold delay stability width
Only available when "USEr" is selected in [ Static hold delay stability criterion].
* Displayed only when two or more expansion heads are connected.
*
Calculation
not used
Calculation mode setting
Calculation mode
Calculation only mode
Only available when an expansion head is connected.
Available to set under the following conditions:
An expansion head is connected.
An item other than "noCALc" is selected for [ Calculation mode].
* This is not displayed when "CAL.noH" is selected for [ Calculation mode].
Calculation method
Max. value
Min. value
Flatness
Average
Reference
difference*
Twist
Warpage
Thickness
[SET] button
[MODE] button
Main screen
Reference The items that can be selected (displayed) are different
depending on the settings in "
A1. Calculation mode". (When
the expansion head is not added, the items that can be
selected (displayed) are the same as for "noCALc".
*1 This can be set only on the main unit that an
expansion head is added.
*2 On the expansion unit, this can be set only when
"C5.rEF (Reference difference) is selected in "A2.
Calculation Mode".
*3 This can be set only when "C5.rEF (Reference
difference)" is selected in "A2. Calculation method".
Normal
Measurement direction change
Reverse
Only available when a value other than "CAL.noH" is selected in [ Calculation mode].
Setting value
input screen
Multiplier
Only available when a value other than "CAL.noH" is selected in [ Calculation mode].
N.O.
Output mode
N.C.
Setting value
input screen
Displayed number of digits
Setting value
input screen
Hysteresis
Separate input
Concurrent input
Batch input setting
Available to set only on the main unit to which an expansion unit is added.
Special output setting
Not used
5-output
Limit output
Limit output user setting
All GO
All limit output
* 1 * 1
O O O O O -
O O* 2 O O O*
3 -
O O - - O O
A1.
Calculation mode
16. Special output
setting
