.Step 8
Confirm.that.there.is.a.piece.of.tubing.on.the.pin.before.
inserting.it.into.the.brace..If.not,.install.a.piece.of.tubing.
to.prevent.vibration.and.radio.interferrence..Slide.the..
short.pins.from.the.strut.ends.into.the.brace.at.the.
fuselage..It.will.be.necessary.to.adjust.the.strut.ends..
to.align.without.binding.or.twisting.the.wing..Once.
adjusted,.tighten.the.4mm.nuts.against.the.ends.to..
prevent.them.from.changing.position.
Note:.Use.threadlock.on.the.strut.
ends.and.4mm.nuts.to.prevent.them.
from.vibrating.loose.in.flight.
.
.Step 9
Secure.the.strut.ends.to.the.wing.using.two.retainer..
pin.clips.
Wing Installation
