.Step 4
Attach.the.tail.wheel.assembly.to.the.fuselage.using.two.
#6.x.5/8-inch.sheet.metal.screws..The.forward.screw.
goes.through.the.gear.and.into.the.fuselage,.while.the.rear.
screw.goes.through.the.two.large.strut.support.brackets,.
then.through.the.gear.and.into.the.fuselage.
.Step 5
Attach.the.two.small.strut.support.brackets.to.the.fin..
using.a.4-40.x.5/8-inch.socket.head.screw.and.a.4-40.
locknut..There.will.be.a.bracket.on.the.right.and.left.of..
the.fin.when.complete.
.Step 6
Remove.the.clevis.from.each.of.the.support.rods..Use.a.
hobby.knife.to.clean.the.paint.from.the.threads..Thread.a.
2-56.nut.onto.the.threads,.then.replace.the.clevis.
.Step 7
Use.a.4-40.x.5/8-inch.socket.head.screw.and.4-40.
locknut.to.attach.the.support.rods.to.the.stabilizer..The.
longer.10-inch.(254mm).rod.attaches.to.the.top.of.the.
stabilizer,.while.the.shorter.9
.
1
/
2
-inch.(241mm).rod.
attaches.to.the.bottom.of.the.stabilizer.
Stabilizer Installation
