Hangar 9 1/4-Scale J-3 Cub ARF - Manual (Page 28)

28
 .Step 8
Thread.a.1-inch.(25mm).threaded.rod.into.each.end.of.
the.throttle.pushrod..Thread.a.metal.clevis.onto.one.of.
the.threaded.rods.and.slide.the.pushrod.into.the.pushrod.
tube..Attach.the.clevis.to.the.arm.of.the.carburetor.
 .Step 9
Secure.the.throttle.servo.in.the.fuselage.using.the.
hardware.provided.with.the.servo..Thread.a.clevis.onto.the.
threaded.rod.and.attach.the.clevis.to.the.servo.arm.
 .Step 10
Check.the.operation.of.the.throttle.servo.to.make.sure.
it.doesn't.bind.and.the.throttle.will.move.from.open.to.
closed..Make.any.adjustment.at.this.time.to.the.throttle.
linkage.as.necessary.
 .Step 11
Slide.the.fuel.tank.into.the.fuselage.with.the.stopper.facing.
toward.the.top.of.the.fuselage..Use.a.rubber.band.to.keep.
the.fuel.tank.from.moving.rearward.in.the.fuselage.
 .Step 12
Use.two.#2.x.1/2-inch.sheet.metal.screws.to.secure.the.
battery.cover.in.position.behind.the.fuel.tank.
Engine Installation (Glow)
