3
Using the Manual
This.manual.is.divided.into.sections.to.help.make.assembly.easier.to.understand,.and.to.provide.breaks.between.each.
major.section..In.addition,.check.boxes.have.been.placed.next.to.each.step.to.keep.track.of.each.step.completed..Steps.
with.a.single.box.(  ).are.performed.once,.while.steps.with.two.boxes.(  .  ).indicate.that.the.step.will.require.
repeating,.such.as.for.a.right.or.left.wing.panel,.two.servos,.etc..Remember.to.take.your.time.and.follow.the.directions.
Required Tools and Adhesives
Tools
•.Rotary.tool.(Dremel). •.Hobby.scissors
•.Pliers. . •.Clamp
•.T-pins. . •.Crimping.tool/vice.grips
•.Solder. . •.String
•.Solder.gun. •.1/4-inch.(6mm).foam
•.Tape. . •.Hobby.knife
•.Phillips.screwdriver. •.Drill
•.Felt-tipped.pen. •.Nut.driver:.1/4-inch
•.Hex.wrench:.5/64-inch,.3/32-inch,.7/64-inch,.1/8-inch
•..Drill.bit:.1/16-inch.(1.5mm),.5/64-inch.(2mm),.5/32-inch.(4mm),.3/16-inch.(4.5mm)
Adhesives
•.Thin.CA.(PAAPT08). •.Medium.CA.(PAAPT02)
•.30-Minute.Epoxy.(HAN8002). •.Formula.560.Canopy.Glue.(PAAPT56)
•.CA.Remover/Debonder.(PAAPT16). •.Pacer.Z-42.Threadlock.(PAAPT42)
UltraCote Covering Colors
•.Cub.Yellow. HANU884
Before Starting Assembly
Before.beginning.the.assembly.of.the.Piper.J-3.Cub,.remove.each.part.from.its.bag.for.inspection..Closely.inspect..
the.fuselage,.wing.panels,.rudder,.and.stabilizer.for.damage..If.you.find.any.damaged.or.missing.parts,.contact.the..
place.of.purchase.
If.you.find.any.wrinkles.in.the.covering,.use.a.heat.gun.or.sealing.iron.to.remove.them..Use.caution.while.working.around.
areas.where.the.colors.overlap.to.prevent.separating.the.colors.
HAN100 – Heat Gun
HAN150 – Covering Glove
HAN101 – Sealing Iron
HAN141 – Sealing Iron
Sock
