Installing Optional Fast Ethernet Interface Modules
2H23-50R/2H33-37R User’s Guide C-7
C.3 INSTALLING OPTIONAL FAST ETHERNET
INTERFACE MODULES
Figure C-3 shows the locations of the Fast Ethernet Interface Module
connectors for ports 5 and 6 on the 2H23-50R, and the High Speed
Interface Module on the 2H33-37R.
Figure C-3 Fast Ethernet Interface Module Connector Location
22861-11
Optional Fast Ethernet
Interface Modules
Connectors
FRONT PANEL
TOP VIEWS WITHOUT COVER
Connector
Optional interface
modules on HSIM FRONT PANEL
Redundant
Power
Supply Primary
Power
Supply
Redundant
Power
Supply Primary
Power
Supply
2H23-50R
2H33-27R
