Chapter 5: Local Management
5-48 2H23-50R/2H33-37R User’s Guide
Figure 5-20 High Speed Interface Configuration Screen
The following briefly defines each field of the High Speed Interface
Configuration screen.
Port Type (Read-only)
Displays the type of interface (FE-100FX, FE-100TX, FE-100F3, or
Unknown) installed in slots 5 and 6.
Figure 5-20 shows that there is an
FE-100TX interface installed in slot 5 and no interface (indicated by
Unknown) in slot 6.
Link Status (Read-only)
Indicates whether or not there is a physical connection from this port to
another 10BASE-T or 100BASE-TX/FX device. One of the following
values displays:
• Link – There is a link signal present and a valid physical connection
to another device.
• No Link – There is no link signal present and no valid physical
connection to another device.
Firmware Revision: XX.XX.XX
High Speed Interface Configuration
22861-24
Device Type: 2H23-50R
BOOTPROM Revision: XX.XX.XX
Port 5
FE-100TX
Link
100Base-TXFD
[Auto-Negotiation]
[100Base-TXFD] [Disabled]
RETURN
2H23-50R LOCAL MANAGEMENT
Event Message Line
SAVE
Port Type
Link Status
Current Oper. Mode
Desired Oper. Mode
Advertised Ability
Port 6
Unknown
N/A
[N/A]
[N/A]
[N/A]
EXIT
