Chapter 4: Troubleshooting
4-2 2H23-50R/2H33-37R User’s Guide
Figure 4-2 LANVIEW LEDs (2H33-37R)
NOTE
The terms flashing, blinking, and solid used in the following
tables indicate the following:
Flashing indicates an LED flashing randomly.
Blinking indicates an LED is flashing at a steady rate
(approximately 50% on, 50% off).
Solid indicates a steady LED light. No pulsing.
12
12
RX
TX
RX
TX
COM
PWR
CPU RESET CONN 1
CONN 3
2H33-37R
10 100
CONN 3
CONN 2
CONN 1 CONN 3
CONN 2
CONN 1 12 1
12 1
2286-36A CPU PWR
Link Speed
