Cabletron Systems 2H23-50R - Manual (Page 137)

RMON Statistics Screen
2H23-50R/2H33-37R User’s Guide 5-87
5.24.2 Using the Clear Counters Command
To reset all the statistics counters of the selected interface to zero, perform
the following steps:
1. Use the arrow keys to highlight the CLEAR COUNTERS command
field.
2. Press ENTER, the counters for the selected interface are reset to zero.
5.25 RMON STATISTICS SCREEN
RMON statistics for each network port, on an port-by-port basis, are
viewed through the RMON Statistics screen shown in
Figure 5-32 .
Access the RMON Statistics screen by using the arrow keys to highlight
the RMON STATISTICS field on the Device Statistics Menu screen and
pressing ENTER. The RMON Statistics screen displays.
Figure 5-32 RMON Statistics Screen
Firmware Revision: XX.XX.XX
RMON Statistics
22861_65
BOOTPROM Revision: XX.XX.XX
RETURN
Device Type: 2H23-50R
RMON Index: X
Data Source: IfIndex.1
Drop Events:
Collisions:
Broadcast Pkts:
Multicasts:
CRC Align Errors:
Undersized Pkts:
Oversized Pkts:
Fragments:
Jabbers:
0
0
0
0
0
0
0
0
0
2H23-50R LOCAL MANAGEMENT
Event Message Line
Index: [ nn] CLEAR COUNTERS EXIT
Owner: monitor
Status: valid
Total Packets:
Total Octets:
64 Octets:
65 - 127 Octets:
128 - 255 Octets:
256 - 511 Octets:
512 - 1023 Octets:
1024 - 1518 Octets:
0
0
0
0
0
0
0
0
