Using LANVIEW
2H23-50R/2H33-37R User’s Guide 4-3
Table 4-1 LANVIEW LEDs
LED Color State Recommended Action
PWR Green Functional. Power
supplies operating
normally. No action.
Amber Indicates loss of power
supply redundancy. 1.Ensure that the power cords
are plugged in correctly and
that there is power at the
power source.
2.If the LED remains amber,
contact the Cabletron
Systems Global Call Center.
CPU Off Power off. Power up device.
Red Blinking. Hardware
failure has occurred. Contact the Cabletron
Systems Global Call Center.
Solid. Resetting,
normal power up reset. No action.
Amber Blinking. Crippled. Contact the Cabletron
Systems Global Call Center.
Solid. Testing. No action.
Green Solid. Functional. No action.
Amber
and
Green Booting. Blinks amber
and green while
booting. No action.
Interface
RX
(Receive)
of
CONN 1–
CONN 4
and Ports 5
and 6
or
CONN 1–
CONN 3
(2H23-50R) Off No link. No activity.
Port enabled or
disabled. No error.
Green Solid. Port enabled,
link, no activity. No error.
Blinking. Port
disabled, link. No error.
Amber Flashing. Port
enabled, link, activity. No error.
Red Diagnostic failure. Contact the Cabletron
Systems Global Call Center
for help.
