Chapter 5: Local Management
5-72
2H23-50R/2H33-37R User’s Guide
To access the Device Level Security Configuration screen, use the arrow
keys to highlight the DEVICE LEVEL SECURITY
CONFIGURATION menu item on the Repeater Configuration Menu
screen and press ENTER. The Device Level Security Configuration
screen displays.
Figure 5-27
Device Level Security Configuration Screen
The following section defines the fields on the Device Level Security
Configuration screen.
Connector (Read-Only)
Indicates the connector. Refer to
for the connector
(CONN)/repeater port relationship on the device.
2H23-50R LOCAL MANAGEMENT
Device Level Security Configuration
Device Type: 2H23-50R Firmware Revision: XX.XX.XX
BOOTPROM Revision: XX.XX.XX
Connector Security State Action On Intruder
1 [PortMismatch]
2 [NonSecure]
3 [NonSecure]
4 [NonSecure]
SAVE EXIT RETURN
2286_112
