Chapter 5: Local Management
5-88 2H23-50R/2H33-37R User’s Guide
The following briefly defines each field of the RMON Statistics screen:
RMON Index (Read-only)
This field displays the current Ethernet interface for which statistics are
being shown. The 2H23-50R or 2H33-37R has an embedded RMON
agent that gathers statistics for each of its interfaces.
Data Source (Read-only)
This field displays the source of the statistics data that is currently being
displayed on the screen.
Figure 5-32 shows that the data source for this
RMON index is Interface 1 (Network Port 1, 10 Mbps of CONN 1) by
displaying the name IfIndex.1. If the screen was displaying RMON
statistics for Interface 4 (Network Port 4, 100 Mbps of CONN 2), the
name displayed would be IfIndex.4.
Table 5-14 shows the association
between the CONN and Network Ports for the 2H23-50R and 2H33-37R.
Owner (Read-only)
This field displays the name of the entity that configured this entry.
Status (Read-only)
The Status field displays the current operating status of the displayed
interface. This field displays “valid” or “invalid”.
Table 5-14 CONN/Network Interfaces
2H23-50R 2H33-37R
CONN 1 = Network Port 1, 10 Mbps
Network Port 2, 100 Mbps
CONN 1 = Network Port 1, 10 Mbps
Network Port 2, 100 Mbps
CONN 2 = Network Port 3, 10 Mbps
Network Port 4, 100 Mbps
CONN 2 = Network Port 3, 10 Mbps
Network Port 4, 100 Mbps
CONN 3 = Network Port 5, 10 Mbps
Network Port 6, 100 Mbps
CONN 3 = Network Port 5, 10 Mbps
Network Port 6, 100 Mbps
CONN 4 = Network Port 7, 10 Mbps
Network Port 8, 100 Mbps
