High Speed Interface Configuration Screen (2H23-50R Only)
2H23-50R/2H33-37R User’s Guide 5-47
5.13 HIGH SPEED INTERFACE CONFIGURATION
SCREEN (2H23-50R ONLY)
To access the High Speed Interface Configuration menu screen from the
Device Specific Configuration Menu screen, use the arrow keys to
highlight the HIGH SPEED INTERFACE CONFIGURATION menu
item and press ENTER. The High Speed Interface Configuration
menu
screen, Figure 5-20 , displays.
The High Speed Interface Configuration screen displays the types of
interfaces installed in slots 5 and 6, their current operating mode, and
indicates if the ports are linked. This screen also allows the user to enable
or disable Auto-Negotiation and set the Advertised Ability.
NOTE
When the HIGH SPEED CONFIGURATION MENU item is
selected for the 2H33-37R, the applicable HSIM Setup screen
displays. Refer to the HSIM user’s guide to set operating
parameters for the HSIM installed in the 2H33-37R.
NOTE
The High Speed Interface Configuration screen, Figure 5-20 ,
applies only to slots 5 and 6 of the 2H23-50R. This screen
supports the FE-100TX, FE-100FX, and FE-100F3 Fast
Ethernet Interface Modules that operate at 100 Mbps.
