Chapter 5: Local Management
5-36 2H23-50R/2H33-37R User’s Guide
5.9 SNMP TRAPS SCREEN
Since the 2H23-50R or 2H33-37R is an SNMP compliant device, it can
send messages to multiple Network Management Stations to alert users of
status changes. The SNMP Traps screen is shown in
Figure 5-16 .
To access the SNMP Traps screen from the Device Configuration Menu
screen, use the arrow keys to highlight the SNMP TRAPS menu item and
press ENTER. The SNMP Traps screen displays.
Figure 5-16 SNMP Traps Screen
The following explains each field of the SNMP Traps screen.
Trap Destination (Modifiable)
Indicates the IP address of the workstation to receive trap alarms. Up to
eight different destinations can be defined.
Trap Community Name (Modifiable)
Displays the Community Name included in the trap message sent to the
Network Management Station with the associated IP address.
Firmware Revision: XX.XX.XX
SNMP Traps
22861-17
Device Type: 2H23-50R
BOOTPROM Revision: XX.XX.XX
Trap Community Name
public
public
public
public
public
public
public
public
2H23-50R LOCAL MANAGEMENT
Event Message Line
RETURN SAVE
Trap Destination
0.0.0.0
0.0.0.0
0.0.0.0
0.0.0.0
0.0.0.0
0.0.0.0
0.0.0.0
0.0.0.0
Enable Traps
[NO]
[NO]
[NO]
[NO]
[NO]
[NO]
[NO]
[NO]
EXIT
