Chapter 4: Troubleshooting
4-6
2H23-50R/2H33-37R User’s Guide
Table 4-3
10/100 LED Indications When RX LED Is Off
NOTE
A link exists if the associated port (5 or 6) RX LED is on.
Table 4-2
10/100 LED Indications When RX LED Is On
LED
Color
Indication
10/100
Off
FE-100TX is operating at 10 Mbps.
Green
FE-100TX is operating at 100 Mbps.
NOTE
No link exists if the associated port (5 or 6) RX LED is off.
LED
Color
Indication
10/100
Off
No link or no cable attached. FE-100TX
forced to 10 Mbps operation, or is
manually set to “auto-negotiate” mode.
Green
No link or no cable attached. FE-100TX is
forced to 100 Mbps operation.
