Brookfield Engineering Labs., Inc. Page 8 Manual No. M/97-164-F1102
SELECT
DISPLAY
SELECT DISPLAY
Selects the data parameter to be displayed:
cP Viscosity (cP or mPa.s)
SS Shear Stress (dynes/cm 2 or Newtons/m 2 )
SR Shear Rate (1/sec)
AUTO
RANGE
ENTER ENTER/AUTO RANGE
ENTER: Used to execute the currently flashing option.
AUTO RANGE: Presents the maximum (100% torque) viscosity attainable using the
selected spindle at the current viscometer spindle speed.
SELECT
SPINDLE
SELECT
SPINDLE
SELECT SPINDLE
Initiates spindle selection on the first press and then selects the currently scrolled-to spindle
when pressed a second time.
PRINT PRINT
Selects printing and non-printing modes when a printer is attached.
TAB
OPTIONS OPTIONS/TAB
OPTIONS: Presents the Options menu, flashing the last escaped option.
TAB: Toggles between selectable items when indicated, as shown in Figure 2.
L °F(FAHRENHEIT)
CGS UNITS
Note: Symbol indicating the
OPTIONS/TAB key
Figure 2
Note: Inverted text (black background with white lettering) indicates that the
information is flashing on the viscometer display.
