Brookfield Engineering Labs., Inc. Page 23 Manual No. M/97-164-F1 102
L °F(FAHRENHEIT)
CGS UNITS
Figure 28
A press of the OPTIONS/TAB key at this point allows the user to “toggle” between the two available
data display units as shown in Figure 29:
L °F(FAHRENHEIT)
CGS UNITS
L °F(FAHRENHEIT)
SI UNITS
Figure 29
Pressing the ENTER/AUTORANGE key selects the display units, which are flashing, followed by an
exit of the Setup menu. You must press the ENTER/AUTORANGE key to select the flashing option.
III.2.3 Motor Speed Set Selection
This selection must be done with the motor off. Scrolling in the Setup options menu to the speed set
selection option yields the following screen display:
L CGS UNITS
SEQUENTIAL
Figure 30
The last selected speed set option is displayed, in this case, Sequential. For each press of the
OPTIONS/TAB key, the display shows selectable options (Figure 31). You must press the ENTER/
AUTORANGE key to select the flashing option.
L CGS UNITS
INTERLEAVE
L CGS UNITS
CUSTOM SPEEDS
L CGS UNITS
SEQUENTIAL
Figure 31
The speeds available in each of the above options are listed in Appendix F. The DV-II+ is initially
set up with the Sequential Speed Set at Brookfield prior to shipment.
III.2.3.1 LV/RV Speeds
In the case of Sequential or Interleave, a press of the ENTER/AUTORANGE key immediately selects
that option and exits the SETUP option menu.
