III.3.1 Time to Stop
On entry, the user is presented with the following screen display:
TIMED STOP
SET MIN’S: 00
Figure 37
Note:
If a time interval has already been set, the user may skip the time interval
input and go directly to the speed input screen (Figure 39) by pressing the
ENTER/AUTORANGE key.
Using the
UP
and
DOWN ARROW
keys, the user enters a value for the minutes portion of the time ramp.
This value can be as high as 59 minutes. When satisfied, the user presses the
OPTIONS/TAB
key again
to enter the seconds setting display:
TIMED STOP
SET SEC’S: 00
Figure 38
Using the
UP
and
DOWN ARROW
keys, the user enters a value for the seconds portion of the time ramp.
This value will be from zero (0 ) up to fifty-nine (59) seconds. Press
ENTER
to accept the value.
Note:
The value for either minutes or seconds must be other than zero or you
cannot advance to the RPM input screen (Figure 39). Pressing the OPTIONS/
TAB or ENTER/AUTORANGE keys will cause the user to alternate between
the minutes input screen (Figure 37) and the seconds input screen (Figure
38) until either minutes or seconds are anything but zero.
A press of the the
ENTER/AUTORANGE
key allows the user to input the RPM selection. At this
point, the user will see a screen similar to Figure 39; using the UP and DOWN ARROW keys,
the user sets the speed.
TIMED STOP
SELECT RPM:30
Figure 39
After selecting the speed, the user may review the values selected. If the user presses the OPTIONS/
TAB key, you will return to the minutes input screen of Figure 37 where you may change the minute
input if so desired. Thereafter, continued pressing of the
OPTIONS/TAB
key will toggle between the
minutes and seconds input screens and the motor input screen. A press of the
MOTOR ON/OFF/
ESCAPE
key will cancel the timed stop operation and take the user back to the screen of Figure 36.
Pressing the
ENTER/AUTORANGE
key will cause the DV-II+ to accept the new values.
