Brookfield Engineering Labs., Inc. Page 32 Manual No. M/97-164-F1102
Refer to Section IV for information on how to create B.E.V.I.S. programs on a PC which can be
downloaded to the DV-II+ Programmable Viscometer.
Press the ENTER/AUTORANGE key to download a B.E.V.I.S. program as shown in Figure 56:
LOAD TO SLOT#1
PRESS ENTER KEY
Figure 56
Select a number from one (1) to four (4) using the UP/DOWN ARROW keys assign a storage location
for the program to be downloaded.
Note: Remember to keep track of what program is in what slot. If you elect to
download a new program to an active slot, you will overwrite the program
currently residing in that slot. The programs are saved automatically when
the viscometer is turned off.
After selecting the slot number, press the ENTER/AUTORANGE key and the screen shown in Figure
56 changes as follows: the top line flashes while the bottom line disappears. This flashing screen
will be displayed for as long as it takes to download the program. At the end of the download, Figure
57 is displayed:
DOWNLOAD DONE TO
EXIT PRESS A KEY
Figure 57
If a PC is not attached, Figure 58 will be displayed:
B.E.V.I.S. ERROR
NO PC ATTACHED
Figure 58
A press of any key (except the MOTOR ON/OFF/ESCAPE key) will take the user back a level to Figure
56 where you may elect to download another program or, with a press of the MOTOR ON/OFF/ESCAPE
key, return to the screen of Figure 55.
III.3.6 Run a Program
In the Options menu, scroll to the screen shown in Figure 59:
DOWNLOAD A PROG
RUN A PROG
Figure 59
Press the ENTER/AUTORANGE key to run a B.E.V.I.S. program as shown in Figure 60:
