Brookfield Engineering Labs., Inc. Page 20 Manual No. M/97-164-F1102
TAB
OPTIONS
OPTIONS/TAB - Toggles between options.
AUTO
RANGE
ENTER ENTER/AUTORANGE - Accepts the currently flashing option and moves
user to next level (if applicable) of the selected
option.
MOTOR
ON/OFF
ESCAPE
MOTOR ON/OFF/ESCAPE - Cancels current operation and backs user out one
menu level. Repeated pressing will back the user
out to the default screen. While in the Options
menu, the
MOTOR ON/OFF/ESCAPE key does not
cause the viscometer motor to turn on or off!
The Options menu screens will appear as shown in Figure 23 if you cycle through the
possible options using the
UP/DOWN arrows.
TIME TO TORQUE
SET PRINT TIME
PC PROG OFF
DOWNLOAD A PROG
DOWNLOAD A PROG
RUN A PROG
SETUP
TIME TO TORQUE
SET PRINT TIME
PC PROG OFF
SETUP
TIME TO STOP
L TIME TO STOP
SET PRINT TIME
SET PRINT TIME
PC PROG ON
L PC PROG ON
DOWNLOAD A PROG
OR
OR
OR
OR
Figure 23
On entry to the Options menu, the following rules regarding current viscometer operation are in force:
1. Printer output will be suppressed when in the Custom Speed option, the Time to
Torque and Time to Stop options, the Download A Program and Run A Program
options. It will be continued when any other option is selected.
2. If the motor is ON when the user enters the Options menu, choices will be limited
to: CGS/SI units (under SETUP),
°
F/
°
C units (under SETUP), PRINTING SELEC-
TIONS and PC PROG.
3. The last selected menu option will be flashing.
